This article outlines the technical specifications and compatibility details of the RAINPOINT ICS006 Water Flow Meter to help determine whether it fits your garden watering setup.
If your product label shows ICS006, you are viewing the correct specifications page.
Product Specifications
| Parameter | Value |
|---|---|
| Model | ICS006 |
| Product Type | Digital Water Flow Meter |
| Waterproof Rating | IPX6 |
| Water Flow Rate | 1–40 L/min (0.3–10.6 GPM) |
| Maximum Flow | 10.6 GPM (2400 L/h) |
| Maximum Water Consumption Display | 9,999.9 L or 9,999.9 gal |
| Working Pressure | 0.5–8 bar (7.25–116 psi) |
| Measurement Tolerance | ±5% |
| Water Temperature | 41°F–104°F (5°C–40°C) |
| Battery | 1 × CR2032 |
| Battery Included | Yes |
| Measurement Modes | FLOW / CONSUMPTION / AVG / TOTAL |
| Flow Units | GAL/Min / L/Min |
| Water Consumption Units | GAL / L |
| US Thread Configuration | NH |
| EU Thread Configuration | BSP |
| Suitable For | Standard 3/4" faucet / hose / sprinkler |
| App Required | No |
| Wi-Fi Required | No |
| Gateway Required | No |
