This article summarizes the key technical specifications and compatibility requirements of the RAINPOINT ITV517P Multi-Program Digital Water Timer to help determine whether it is suitable for a specific watering setup.
Product Specifications
| Parameter | Value |
| Water Pressure | 7–116 psi (0.5–8 bar) |
| Watering Frequency | Every 6, 8, or 12 hr; every 1–7 days; or selected weekdays |
| Watering Duration | 1 min–3 hr 59 min |
| Programs | Plan 1 / Plan 2 / Plan 3 |
| Rain Delay | 0, 24, 48, or 72 hr |
| Battery Type | 2 × AAA alkaline batteries |
| Water Inlet | NH (US): 3/4"; BSP (EU): 3/4" or 1" |
| Water Outlet | Standard 3/4" garden hose connection |
| Waterproof Level | IP54 |
| Operating Temperature | 37.4°F–122°F (3°C–50°C) |
Common Compatible Setups
