This article outlines the technical specifications and compatibility details of the RAINPOINT HTP160FRF Wi-Fi Outdoor Solar Automatic Drip Irrigation Pump Kit to help determine whether it fits your watering and network setup.
If your pump is labeled HTP160FRF and your Gateway is labeled HWG023WBRF, you are viewing the correct specifications page.
Product Specifications
| Parameter | Value |
|---|---|
| Pump Model | HTP160FRF |
| Gateway Model | HWG023WBRF |
| Product Type | Wi-Fi Outdoor Solar Automatic Drip Irrigation Pump Kit |
| Pump Working Temperature | 37°F–122°F (3°C–50°C) |
| Solar Panel Output | 5V / 1.5W |
| Pump Charging Input | USB-C, 5V / 1A |
| Battery Capacity | 2000 mAh |
| Flow Rate | 30 L/h |
| Max Head | 3 m |
| Recommended Max Height Difference | ≤ 6.6 ft (2 m) |
| Waterproof Rating | IPX5 |
| Inlet & Outlet Diameter | 4 mm |
| Water Type | Clean, cold water only |
| Main Line Tubing | 49.2 ft (15 m), 1/6" (4 mm) inner diameter |
| Branch Line Tubing | 16.4 ft (5 m), 1/8" (3 mm) inner diameter |
| Pump–Gateway Communication | 433 MHz RF |
| Pump–Gateway Range | Less than 492 ft (150 m), line of sight |
| Gateway Power Supply | USB-C power adapter |
| Gateway Operating Temperature | 37.4°F–104°F (3°C–40°C) |
| Wi-Fi Frequency Band | 2.4 GHz |
| Mobile OS Requirements | iOS 11.0 or later; Android 6.0 or later |
| App | RainPoint Home |
| Maximum Watering Schedules | Up to 6 |
| Rain Delay | 24, 48, or 72 hours |
| Manual Watering | Pump button or RainPoint Home app |
| Installation Options | Ground stake, wall mount, or back hook |
| Water Source | Water container / reservoir |
| Pump Placement | At or above reservoir water level |
Common Compatible Setups
