This article outlines the technical specifications and compatibility details of the RAINPOINT TCS005FRF Soil Moisture Sensor to help determine whether it fits your RAINPOINT irrigation setup.
If your product label shows TCS005FRF, you are viewing the correct specifications page.
Product Specifications
| Parameter | Value |
|---|---|
| Model | TCS005FRF |
| Product Type | Soil Moisture & Temperature Sensor |
| Power Supply | 3 × AAA 1.5V alkaline batteries |
| Battery Life | Over 1 year |
| Data Update Interval | Every 5 minutes |
| RF Frequency | 433.92 MHz FSK |
| Soil Moisture Range | 0%–100% VWC |
| Soil Moisture Accuracy | ≤5% at 0%–50% VWC; ≤10% at 51%–100% VWC |
| Soil Temperature Range | -10°C–60°C (14°F–140°F) |
| Selectable Moisture Levels | 20% / 40% / 60% / 80% / 100% |
| Default Stop Watering Level | 60% |
| RF Range | Within 100 m / 328 ft in an open area |
| Waterproof Rating | IP67 |
| Manual Soil Moisture Check | Supported |
| Soil Temperature Monitoring | Supported |
| App Data Viewing | Supported through Control Master App |
| Compatible Water Timers Listed in Manual | TTV103WRF / TTV203WRF |
| Standalone Wi-Fi Connection | Not described |
| Separate Gateway Required | Not described |
