This article outlines the technical specifications and compatibility details of the RAINPOINT ICS518 Hose-end High Precision Flow Meter to help determine whether it fits your garden watering setup.
If your product label shows ICS518, you are viewing the correct specifications page.
Product Specifications
| Parameter | Value |
|---|---|
| Model | ICS518 |
| Product Type | Hose-end High Precision Flow Meter |
| Waterproof Rating | IPX6 |
| Water Flow Rate | 0.5–40 L/min (0.13–10.6 GPM) |
| Maximum Flow Rate | 2400 L/h (636 GPH) |
| Maximum Water Consumption Display | 9,999.9 L or 9,999.9 gal |
| Working Pressure | 0.5–8 bar (7.25–116 psi) |
| Measurement Tolerance | ±3%* |
| Power Supply | 1 × CR2032 button cell |
| Battery Included | Yes |
| Measurement Modes | FLOW / CONSUMPTION / AVG / TOTAL |
| Unit Selection | GAL / L |
| USA Connector | 3/4" NH thread |
| EU Connector | 3/4" BSP thread |
| App Required | No |
| Wi-Fi Required | No |
| Gateway Required | No |
Common Compatible Setups
