This article outlines the technical specifications and compatibility details of the RAINPOINT IK153 Indoor Irrigation Kit.
If your product label shows IK153, you are viewing the correct specifications page.
Product Specifications
| Parameter | Value |
|---|---|
| Model | IK153 |
| Product Type | Indoor Irrigation Kit |
| Working Temperature | 3°C–50°C (37°F–122°F) |
| Power Supply | Type-C, 5V/1A |
| Battery Capacity | 2000 mAh |
| Max Flow Rate | 30 L/h (7.93 gal/h) |
| Max Head | More than 3 m (118 in) |
| Applicable Height Difference | ≤ 2.5 m (8.2 ft) |
| Main Line Tubing | 15 m (49.2 ft), 4 mm (1/6") inner diameter |
| Branch Line Tubing | 5 m (16.4 ft), 3 mm (1/8") inner diameter |
| Micro Drip Emitters | 20 |
| Watering Start Time | Supported |
| Watering Duration | Supported |
| Watering Frequency | Every 8h, 12h, or 1–30 days |
| Cycle & Soak | Supported |
| Rain Delay | 24h / 48h / 72h |
| Manual Watering | Supported |
| Water Shortage Alert | Supported |
| Water Source | Reservoir / water container |
| Application | Indoor drip irrigation |
Common Compatible Setups
