This article outlines the technical specifications and compatibility details of the RAINPOINT HTP159W Wi-Fi Automatic Indoor Watering Pump Kit to help determine whether it fits your indoor watering and Wi-Fi setup.
If your product label shows HTP159W, you are viewing the correct specifications page.
Product Specifications
| Parameter | Value |
|---|---|
| Model | HTP159W |
| Product Type | Wi-Fi Automatic Indoor Watering Pump Kit |
| Operating Temperature | 37°F–122°F (3°C–50°C) |
| Power Supply | USB-C |
| Recommended Charging Adapter | DC 5V / 1A |
| Flow Rate | 30 L/h |
| Max Head | 3 m |
| Applicable Height Difference | ≤ 6.6 ft (2 m) |
| Inlet & Outlet Outer Diameter | 4 mm |
| Wi-Fi Connection Range | Up to 262 ft (80 m) in open, unobstructed areas with minimal interference |
| App | RainPoint Home |
| Wi-Fi Setup | Select 2.4 GHz when separate networks are shown; combined networks can continue setup |
| Maximum Watering Schedules | Up to 6 |
| Watering Modes | Normal Irrigation / Cycle & Soak |
| Rain Delay | 24 / 48 / 72 hours |
| Seasonal Adjustment | Supported |
| Manual Watering | Pump button / RainPoint Home app |
| Low Water Detection | Supported |
| Water Shortage Calibration | Supported |
| Sensitivity Adjustment | Supported |
| Power-Saving Setting | Supported |
| Main Line Tubing | 49.2 ft (15 m), 1/6" (4 mm) inner diameter |
| Branch Line Tubing | 16.4 ft (5 m), 1/8" (3 mm) inner diameter |
| Included Micro Drip Emitters | 15 |
| Water Type | Clean, cold water only |
| Water Source | Water container / reservoir |
| Pump Placement | At or above reservoir water level |
| Installation Accessory | Detachable rear hook |
| Gateway Required | No Gateway listed in the current manual |
| Intended Application | Indoor automatic drip irrigation for plants |
