This article outlines the technical specifications and compatibility details of the RAINPOINT TTP106W WiFi Automatic Watering Pump Kit.
If your product label shows TTP106W, you are viewing the correct specifications page.
Product Specifications
| Parameter | Value |
|---|---|
| Model | TTP106W |
| Product Type | WiFi Automatic Watering Pump Kit |
| Working Pressure | 0.3 Bar |
| Water Flow | 30 L/h |
| Maximum Water Pressure | ≥200 kPa |
| Pump Head | 2–3 m |
| Pumping Distance | 2–3 m |
| Waterproof Rating | IPX2 |
| Working Temperature | 3°C–50°C (37°F–122°F) |
| Material | ABS |
| Power Supply | USB cable / 4 × AA batteries |
| Wi-Fi Frequency | 2.4 GHz |
| Wi-Fi Control | Supported |
| App | RainPoint-Tuya |
| Watering Duration | 20 seconds–30 minutes |
| Watering Frequency | 0–23h 59min or 1–7 days |
| Delay Function | 1–24 hours |
| Main Tubing Length | 10 m / 32.8 ft |
| Tubing Inner Diameter | 0.17" (>1/6") |
| Included Micro Drippers | 10 |
| Switch Valves | 10 |
| Water Source | Water container |
| Application | Drip irrigation |
