This article outlines the technical specifications and compatibility details of the RAINPOINT TTV102B | 1-Zone Water Timer to help you determine whether it fits your watering setup.
If your product label shows TTV102B, you are viewing the correct specifications page.
Product Specification
Parameter |
Value |
|---|---|
| Water Pressure | 7–116 psi (0.5–8 bar) |
| Battery Type | 3 × AA alkaline batteries |
| Maximum Flow Rate | 10 Gal/min (35 L/min) |
| Compatible Faucet Size | 3/4" NH (US); 3/4" or 1" BSP (EU) |
| Operating Temperature | 37.4°F – 122°F (3°C – 50°C) |
| Water Type | Clean, cold water only |
| Use Environment | Outdoor use only |
| Water Resistance Rating | IP54 |
Common Compatible Setups
补充对应图片
The RAINPOINT TTV102B is currently available in two common configurations:
Standalone Timer
Includes the TTV102B timer only
Supports Bluetooth control for local operation
Suitable for users who prefer on-site control
Gateway Bundle (Recommended)
Includes the TTV102B timer + RainPoint Gateway
Enables Wi-Fi remote control via the RainPoint app
Supports voice control through Google Assistant and Amazon Alexa
Allows remote valve on/off operation and smart scheduling
⚠️ Note:
Wi-Fi remote access and voice assistant features require the RainPoint Gateway.
